TP-Link Omada ES206X-M2 2.5G Easy Managed Network Switch, 5× 2.5GbE Ports + 10G SFP+, Fanless Design, VLAN, QoS, IGMP Snooping, 5-Year Warranty

TP-Link Omada ES206X-M2 2.5G Easy Managed Network Switch, 5× 2.5GbE Ports + 10G SFP+, Fanless Design, VLAN, QoS, IGMP Snooping, 5-Year Warranty

SPECIFICATION

HARDWARE FEATURES

Interface
•5× 2.5 Gbps RJ45 Ports
•1× 10 Gbps SFP+ Slot
•Auto-Negotiation/Auto MDI/MDIX
Fan Quantity
•Fanless
Installation
•Desktop
•Wall Mount
Physical Security Lock
•?
Power Supply
•DC Power Adapter
•(Output: 12 VDC / 1 A)
Dimensions ( W x D x H )
•6.2 × 4.0 × 1.0 in (158 × 100.7 × 25.4 mm)
Surge Protection
•±6kV for Ethernet Ports

SOFTWARE FEATURES

Quality of Service
• Port-based/802.1p/DSCP QoS?
• 8 Priority Queues
• Priority Schedule Mode
- WRR (Weighted Round Robin)
• Queue Weight Config
• Bandwidth Control
- Port-Based Rating Limit
• Storm Control
- Multiple Control Modes (kbps/pps)
- Broadcast/Multicast/Unknown-Unicast Control

L2 Features
• Static Link Aggregation
• Loop Prevention / Loopback Detection
• Flow Control
- 802.3x Flow Control
• Mirroring
- Port Mirroring
- One-to-One
- Many-to-One
- Ingress/Egress/Both
• Port Statistics
- Port Mirror Status
- Traffic Statistics
• 802.1ab LLDP

L2 Multicast
• IGMP Snooping
- IGMP v1/v2/v3 Snooping
- Fast Leave

VLAN
• MTU VLAN
• Port-Based VLAN
• 802.1Q Tag VLAN
- Max 32 VLAN Groups
- 4K VID
Transmission Method
•Store-And-Forward

Warranty Period: 5-Year
